Multi-Cavity Molds: When They Pay Off and When They Don't

The basic trade: tooling cost against per-unit output

A single-cavity mold costs less to build and is easier to balance and maintain, but produces one part per cycle. A multi-cavity mold, 2, 4, 8, or more, multiplies output per cycle at the cost of a more complex, more expensive tool that has to hold tighter balance across every cavity simultaneously. The decision is fundamentally an amortization question: does the annual volume justify the higher upfront tooling cost against the per-unit savings from higher cavitation.

Where the volume threshold typically sits

As a rough guide, programs under roughly 250,000 to 500,000 units annually often don't clear the payback threshold for going beyond a 2-cavity tool, the added tooling cost per cavity doesn't amortize fast enough against a modest annual run rate. Programs in the multiple-millions-of-units range routinely justify 8, 16, or higher cavitation, where the per-unit tooling amortization becomes small enough that cycle-time throughput dominates the economics.

Cavity balance is where multi-cavity tools actually get hard

The engineering challenge in multi-cavity tooling isn't cutting more cavities, it's making sure melt fills every cavity at the same rate, pressure, and temperature, which requires balanced runner design, often naturally balanced (geometrically symmetric) rather than artificially balanced through gate sizing tricks. An unbalanced multi-cavity mold produces parts with cavity-to-cavity variation in wall thickness, weight, and dimensional accuracy, sometimes enough to fail a customer's incoming inspection on some cavities and not others.

What this means when you're comparing quotes

A lower per-unit price on a multi-cavity quote isn't automatically the better deal if your annual volume doesn't support the tool amortizing within the program's expected lifespan. Ask what cavity count a quote assumes and what the tooling cost looks like at both a lower and higher cavitation option, the crossover point is specific to your volume, not a fixed rule.

How we scope it

We size cavitation to your actual forecast volume, not the highest number that fits the press, and we build runner balance verification into first-article inspection so cavity-to-cavity variation gets caught before a full production run ships. For related tooling decisions, see Wall Thickness, Draft Angles, and Gate Placement.
